45° Double Socket Bend

Ductile Iron Push-on Fitting EN545 ISO2531

Application: Municipal Use, Waterworks Pipelines, Piping Fittings, Water Engineering, Potable Water Use, Irrigation Use, Water Supply Project Use, Water Treatment Plants Use, Pumping Stations, Water Utility Sectors, Water-Supply Pressure Pipeline, Potable Water Pumping Station, Stormwater Lines, Fire Water Pumping Station, Fresh Water Pumping Station, ect.

Introduction

DI Socket Fittings With Push-on On Joint(Tyton Joint)






Specification:
DN50-DN2000(2"-80"), available with PN10, PN16, PN25 and PN40 flanges

Ductile Iron Flange Fittings Standard: ISO2531, ISO4179, ISO8179, BS EN 545, BS EN598, BS4772, ISO7005-2, EN1092-2:1997, DIN2501, GBT13295

Flange: PN10, PN16 or PN25 drilling in accordance with ISO 7005-2/EN 1092-2.

Fluid Temperature: 0°C-50°C, excluding frost.

Pipe ends: Spigot, socket or flanges.

Internal coating: Cement mortar lining comply with ISO4179 or bitumen painting (Ave. min.70 micron) or Fusion Bonded Epoxy Coating

External coating: Sprayed metallic zinc coating (min.150g/m²) according to ISO8179 + bitumen painting (min.70 micron) or epoxy powder coating or epoxy painting or according to customer’s requirements.

Types: Dismantling Joint, Universal Flange Adaptor, Universal Coupling, Ductile Iron Loose Flange Joint, DI Pipe Fitting, Saddle for PVC Pipe, Repair Clamp, Qucick Flange Adaptor, Gibault Joint, Restrained Flange Adaptor, Restrained Coupling, Valve, etc.

Material: MATERIAL: Ductile iron grade 500-7/ 450-12 in accordance with ISO 1083 for ductile iron fitting body and retainer, EPDM/NBR for ring, steel zinced/dacro for stub.

Application: Municipal Use, Waterworks Pipelines, Piping Fittings, Water Engineering, Potable Water Use, Irrigation Use, Water Supply Project Use, Water Treatment Plants Use, Pumping Stations, Water Utility Sectors, Water-Supply Pressure Pipeline, Potable Water Pumping Station, Stormwater Lines, Fire Water Pumping Station, Fresh Water Pumping Station, ect.

Test: In accordance with ISO 2531 / EN 545 / EN598 and 100% water pressure test.


Push on joint can assembled by pushing the spigot through the gasket in the socket of the mating component, and permits significant angular deflextion both during and after installation and which can accept a light offset of the centreline. As the Ductile Iron Push-on joint fitting manufacturer in China and Ductile Iron Push-on joint fitting factory, we hope working with you, we are eager to get your inquiries and establish long term mutual benefit cooperation relationship.


Dimensions of 45° Double Socket Bend

DNLMass (kg)standard
80557.7ISO2531/EN545
1006510.1ISO2531/EN545
1257513.6ISO2531/EN545
1508517.4ISO2531/EN545
20011027ISO2531/EN545
25013038.5ISO2531/EN545
30015053ISO2531/EN545
35017570ISO2531/EN545
40019589ISO2531/EN545
500240139ISO2531/EN545
700330282ISO2531/EN545
