Ductile Iron Saddle

Dismantling Joint And Flange Adaptor

Types: Dismantling Joint, Universal Flange Adaptor, Universal Coupling, Ductile Iron Loose Flange Joint, DI Pipe Fitting, Saddle for PVC Pipe, Repair Clamp, Qucick Flange Adaptor, Gibault Joint, Restrained Flange Adaptor, Restrained Coupling, Valve, etc.

Material: MATERIAL: Ductile iron grade 500-7/ 450-12 in accordance with ISO 1083 for ductile iron fitting body and retainer, EPDM/NBR for ring, steel zinced/dacro for stub.


Introduction

Specification: DN50-DN2000(2"-80"), available with PN10, PN16, PN25 and PN40 flanges

Ductile Iron Flange Fittings Standard: ISO2531, ISO4179, ISO8179, BS EN 545, BS EN598, BS4772, ISO7005-2, EN1092-2:1997, DIN2501, GBT13295

Flange: PN10, PN16 or PN25 drilling in accordance with ISO 7005-2/EN 1092-2.

Fluid Temperature: 0°C-50°C, excluding frost.

Pipe ends: Spigot, socket or flanges.

Internal coating: Cement mortar lining comply with ISO4179 or bitumen painting (Ave. min.70 micron) or Fusion Bonded Epoxy Coating

External coating: Sprayed metallic zinc coating (min.150g/m²) according to ISO8179 + bitumen painting (min.70 micron) or epoxy powder coating or epoxy painting or according to customer’s requirements.

Types: Dismantling Joint, Universal Flange Adaptor, Universal Coupling, Ductile Iron Loose Flange Joint, DI Pipe Fitting, Saddle for PVC Pipe, Repair Clamp, Qucick Flange Adaptor, Gibault Joint, Restrained Flange Adaptor, Restrained Coupling, Valve, etc.

Material: MATERIAL: Ductile iron grade 500-7/ 450-12 in accordance with ISO 1083 for ductile iron fitting body and retainer, EPDM/NBR for ring, steel zinced/dacro for stub.

Application: Municipal Use, Waterworks Pipelines, Piping Fittings, Water Engineering, Potable Water Use, Irrigation Use, Water Supply Project Use, Water Treatment Plants Use, Pumping Stations, Water Utility Sectors, Water-Supply Pressure Pipeline, Potable Water Pumping Station, Stormwater Lines, Fire Water Pumping Station, Fresh Water Pumping Station, ect.

Test: In accordance with ISO 2531 / EN 545 / EN598 and 100% water pressure test.


Dimensions of Ductile Iron Saddle

Ductile Iron saddle outlets are an economical alternative to tee fittings and welded-on bosses in new construction. Because it can be placed anywhere on the pipe barrel, no cuts have to be made, saving time and money. It is made of ductile iron and has rubber sheet inside, 2 bolts and 4 bolts are available. As the Ductile Iron saddle outlets manufacturer in China and Ductile Iron saddle outlets factory, we hope working with you, we are eager to get your inquiries and establish long term mutual benefit cooperation relationship.


NO. PVC saddle clampThread sizeSuit pipe OD(mm)
1501/2. 3/4. 1.DE=50 mm
2631/2. 3/4. 1.DE=63 mm
3751/2. 3/4. 1.DE=75 mm
4901/2. 3/4. 1.DE=90 mm
51101/2. 3/4. 1.DE=110mm
61251/2. 3/4. 1.DE=125 mm
71401/2. 3/4. 1.DE=140 mm
81601/2. 3/4. 1.DE=160 mm
92001/2. 3/4. 1.DE=200mm
102251/2. 3/4. 1.DE=225 mm
112501/2. 3/4. 1.DE=250mm
122801/2. 3/4. 1.DE=280 mm
133151/2. 3/4. 1.DE=315 mm
14501 1/4. 1 1/2.DE=50 mm
15631 1/4. 1 1/2.DE=63 mm
16751 1/4. 1 1/2.DE=75 mm
17901 1/4. 1 1/2.DE=90 mm
181101 1/4. 1 1/2.DE=110mm
191251 1/4. 1 1/2.DE=125 mm
201401 1/4. 1 1/2.DE=140 mm
211601 1/4. 1 1/2.DE=160 mm
222001 1/4. 1 1/2.DE=200mm
232251 1/4. 1 1/2.DE=225 mm
242501 1/4. 1 1/2.DE=250mm
252801 1/4. 1 1/2.DE=280 mm
263151 1/4. 1 1/2.DE=315 mm
27502DE=50 mm
28632DE=63 mm
29752DE=75 mm
30902DE=90 mm
311102DE=110mm
321252DE=125 mm
331402DE=140 mm
341602DE=160 mm
352002DE=200mm
362252DE=225 mm
372502DE=250mm
382802DE=280 mm
393152DE=315 mm
