Loosing Flanged Anchoring Sleeve

Ductile iron Loosing Flange Fitting

Application: Municipal Use, Waterworks Pipelines, Piping Fittings, Water Engineering, Potable Water Use, Irrigation Use, Water Supply Project Use, Water Treatment Plants Use, Pumping Stations, Water Utility Sectors, Water-Supply Pressure Pipeline, Potable Water Pumping Station, Stormwater Lines, Fire Water Pumping Station, Fresh Water Pumping Station, ect.

Introduction






Specification: DN50-DN2000(2"-80"), available with PN10, PN16, PN25 and PN40 flanges

Ductile Iron Flange Fittings Standard: ISO2531, ISO4179, ISO8179, BS EN 545, BS EN598, BS4772, ISO7005-2, EN1092-2:1997, DIN2501, GBT13295

Flange: PN10, PN16 or PN25 drilling in accordance with ISO 7005-2/EN 1092-2.

Fluid Temperature: 0°C-50°C, excluding frost.

Pipe ends: Spigot, socket or flanges.

Internal coating: Cement mortar lining comply with ISO4179 or bitumen painting (Ave. min.70 micron) or Fusion Bonded Epoxy Coating

External coating: Sprayed metallic zinc coating (min.150g/m²) according to ISO8179 + bitumen painting (min.70 micron) or epoxy powder coating or epoxy painting or according to customer’s requirements.

Types: Dismantling Joint, Universal Flange Adaptor, Universal Coupling, Ductile Iron Loose Flange Joint, DI Pipe Fitting, Saddle for PVC Pipe, Repair Clamp, Qucick Flange Adaptor, Gibault Joint, Restrained Flange Adaptor, Restrained Coupling, Valve, etc.

Material: MATERIAL: Ductile iron grade 500-7/ 450-12 in accordance with ISO 1083 for ductile iron fitting body and retainer, EPDM/NBR for ring, steel zinced/dacro for stub.

Application: Municipal Use, Waterworks Pipelines, Piping Fittings, Water Engineering, Potable Water Use, Irrigation Use, Water Supply Project Use, Water Treatment Plants Use, Pumping Stations, Water Utility Sectors, Water-Supply Pressure Pipeline, Potable Water Pumping Station, Stormwater Lines, Fire Water Pumping Station, Fresh Water Pumping Station, ect.

Test: In accordance with ISO 2531 / EN 545 / EN598 and 100% water pressure test.


All Loosing Flanged Tee All Loosing Flanged Cross Double Loosing Flanged Duckfoot Bend Double Loosing Flanged anchoring Sleeve Loosing Flanged Spigot Loosing Flange Set . Standard: ISO2531,EN545,EN598 Pressure: PN10/PN16/PN25/PN40 Body material : Ductile iron Coating: a). Inside and outside with FBE ( fusion bonded epoxy) coating or Epoxy. As the Ductile Iron All Loosing Flanged Tee manufacturer in China and Ductile Iron All Loosing Flanged Tee factory, we hope working with you, we are eager to get your inquiries and establish long term mutual benefit cooperation relationship.


Dimensions of Loosing Flanged Anchoring Sleeve

DNLMass without loosing flanges (kg)Mass with loosing flanges PN10 (kg)Mass with loosing flanges PN16 (kg)
8080015.219.819.8
10080019.324.324.3
1258002531.431.4
15080030.839.239.2
200800445655.8
25080058.475.674.8
300100090.5113.1111.7
4001000113.6146.6155.6
