Spectacle Blind Flange

Flange

Spectacle Blind Flange Size:  1/2" ~ 24" (DN15 ~ DN600)

Spectacle Blind Flange Pressure Ratings: Class 150, Class 300LB, Class 600LB, Class 900LB;

Surface treatment: antirust oil, black / yellow / transparent / electric galvanized / hot galvanized

Packing: sea-worthy packing in wooden cases or on wooden pallets or as per customers' special requirement

Min Order Quantity: According to customer's requirement.

Delivery: 30 days after receiving the formal order;

Payment: By T/T or L/C.

Applications range: Petroleum, chemical industry, water conversancy, electric power, Natural gas, Coal gas, Water power and other pipeline projects.

More information is available upon receipt of your enquiry, Eathu also can produce the flange accroding to your drawing.

Introduction

ASME/ANSI B16.48 Paddle Blind/Paddle Space/Figure 8 Blind


SPECTACLE BLIND FLANGE is a combination of the two that can be rotated to function as Single Bind or a Ring Spacer. This kind of flange is generally a piece of metal than is cut to fit between two pipe flanges and usually sandwiched between two gaskets a spectacle blind is often made from two metal discs that are attached to each other by a small section of steel. The Sharp is similar to a pair of glasses or spectacles – hence the name spectacle blind flange. One end of the blind will have an opening to allow flow through the pipe during operation and the other end is solid to block flow during maintenance. They are generally installed as a permanent device to separate process piping system.


The whole idea of a spectacle blind is so that one can be absolutely sure that an item of equipment is properly and securely blanked off with no possibility of any flow or leakage through a valve during maintenance. The flow can be diverted to other items of equipment but not just by passed around the blank as this would compromise the safety function of the spectacle blind. The flow has to valve off and pressure relieved prior to loosening flange bolts and swinging the blind.




Type 1: Paddle Blind                  Type 2: Paddle Space                Type 3: Figure 8 Blind



DIMENSIONS OF CALSS 150 RAISED FACE FIGURE 8 BLANKS

NPSInsideOutsideCenterlineThicknessTie bar
DiameterDiameterDimensiont.in.W.in.
B.in.O.in.A.in.

1/20.621.752.380.121.50
3/40.822.122.750.121.50
11.052.53.120.121.50
1.1/41.662.883.50.251.50
1.1/21.93.253.880.251.50
22.3844.750.252.00
2.1/22.884.755.50.252.00
33.55.2560.252.50
3.1/246.2570.382.50
44.56.757.50.382.50
55.667.628.50.383.00
66.628.629.50.53.00
88.6210.8811.750.53.00
1010.7513.2514.250.624.00
1212.7516170.754.00
141417.6218.750.754.25
161620.1221.250.884.25
181821.522.7514.50
202023.75251.124.75
242428.1229.51.255.50

DIMENSIONS OF CALSS 300 RAISED FACE FIGURE 8 BLANKS

NPSInsideOutsideCenterlineThicknessTie bar
DiameterDiameterDimensiont.in.W.in.
B.in.O.in.A.in.

1/20.6202.620.251.50
3/40.822.53.250.251.50
11.052.753.50.251.50
1.1/41.663.123.880.251.50
1.1/21.93.624.50.252.00
22.384.2550.382.00
2.1/22.8855.880.382.50
33.55.756.620.382.50
3.1/246.387.250.52.50
44.577.880.52.50
55.568.389.250.623.00
66.629.7510.620.623.00
88.6212130.883.50
1010.7514.1215.2514.00
1212.7516.517.751.124.00
14141920.251.254.75
161621.1222.51.54.88
181823.3824.751.624.50
202025.62271.754.75
242430.383225.50


DIMENSIONS OF CALSS 600 RAISED FACE FIGURE 8 BLANKS

NPSInsideOutsideCenterlineThicknessTie bar
DiameterDiameterDimensiont.in.W.in.
B.in.O.in.A.in.

1/20.6222.620.251.50
3/40.822.53.250.251.50
11.052.753.50.252.25
1.1/41.443.123.880.382.25
1.1/21.683.624.50.382.62
22.164.2550.382.25
2.1/22.6455.880.52.62
33.265.756.620.52.62
3.1/23.766.257.250.623.00
44.267.58.50.623.00
55.39.3810.50.753.38
66.3610.3811.50.883.38
88.3312.513.751.123.75
1010.4215.62171.384.12
1212.3917.8819.251.624.12
1413.6219.2520.751.754.50
1615.6222.1223.7524.88
1817.622425.752.125.25
2019.5626.7528.52.55.25
2423.531332.886.00


DIMENSIONS OF CALSS 900 RAISED FACE FIGURE 8 BLANKS

NPSInsideOutsideCenterlineThicknessTie bar
DiameterDiameterDimensiont.in.W.in.
B.in.O.in.A.in.

1/20.622.383.250.251.50
3/40.822.623.50.251.62
11.05340.252.25
1.1/41.443.384.380.382.25
1.1/21.683.754.880.382.62
22.165.56.50.52.25
2.1/22.646.387.50.52.62
33.266.57.50.622.62
44.2689.250.753.00
55.39.62110.883.38
66.3611.2512.513.38
88.331415.51.383.75
1010.421718.51.624.12
1212.3919.5211.884.12
1413.6220.38222.124.50
1615.6222.524.252.384.88
1817.6225272.625.25
2019.5627.3829.52.885.25
2423.532.8835.53.56.00
