Socket Weld 45 Degree Elbow

Forged Pipe Fittings

Manufacturer of ASME B16.11 3000LB, 6000LB, 9000LB Forged Pipe Fittings in China.


Product Name: elbow, tee, cap, bushing, coupling, pipe nipple, hex, nipple, weldolet, threadolet, sockolet, socket, cap, cross, flangolet, union, swage nipple, etc..


Size: 1/8"-4" threaded and socket weld type


Pressure:

Socket weled : 3000LB  6000LB  9000LB (sch80 sch160 xxs)

Threaded : 2000LB  3000LB  6000LBS (sch80 sch160 xxs)


Conection: Thread (NPT, BSP,RP, G) ,Socket Welding


Type: Elbow,Tee,nipple,full coupling, half coupling,lateral,cross,cap, plug,hex head nipple, swage nipple,union,weldolet,sockolet, threadolet, nipolet, elbolet, latrolet etc.


Standard: ANSI B16.11,EN10241, BS3799,JIS B2316,MSS SP-83,MSS SP-79;


Surface Treatment: Sand blasting, Anti-rust oil, Galvanized, Polished, black.


Wall thickness: SCH5S, SCH10S, SCH10, SCH40S,STD, XS, XXS, SCH20,SCH30,SCH40, SCH60, SCH80, SCH160, XXS and etc.


Material:

Stainless steel: A182 F304/304L, A182 F316/316L, A182 F321, A182 F310S, A182 F347H, A182 F316Ti, A182 F317, 904L, 1.4301,1.4307,1.4401,1.4571,1.4541, 254Mo and etc.

Carbon steel: ASTM A105, A350LF2, Q235, St37, 20#, 16Mn, St45.8, A42CP, E24 , A515 Gr60, A515 Gr 70, A420 WPL6 etc.

Duplex stainless steel: UNS31803, SAF2205, UNS32205, UNS31500, UNS32750 , UNS32760, 1.4462,1.4410,1.4501 and etc.

Pipeline steel: A694 F42, A694F52, A694 F60, A694 F65, A694 F70, A694 F80 etc.

Nickel alloy: inconel600, inconel625, inconel690, incoloy800, incoloy 825, incoloy 800H, C22, C 276, Monel400, Alloy20 etc.

Cr-Mo alloy: A182 F11,A182 F5, A182 F22, A182 F91, A182 F9, 16mo3 etc.


Application: Petroleum Chemical,Refinery, Pharmacy Industry, Food & Beverage Industry, Sea Water Desalination,Paper Making, Shipbuilding Industry, Electric power, Offshore & onshore oil&gas, Mining Industry, Water Treatment, Mechanical Making, Chemical fertilizer etc.


Package: Cartons in wooden cases.

MOQ: to be negotiated.

Sample: Available

Price: >>DOWNLOAD the forged fittings newest price list from PRICE LIST AND TECH

Service: Customized OEM

Payment term: T/T or L/C

Delivery:7-30days according to order quantity.

Introduction

Socket Weld Elbow:In pipeline system, the elbow is to change the direction of the pipeline. According to the view points, there are 45 degree, 90 degree, 180 degree three most commonly used types, according to the requirements of the project ,also includes 60 degree and other abnormal Angle elbows .Socket weld elbow, mainly manufactured by round steel or steel ingot .Heat the steel ingot, put them in mold cavities,then forging to blanks by forging machine, and then after the lathe machining forming a high pressure elbow pipe fitting.


Socket Weld 45 Degree Elbow Dimension


DNNom.Center to Bottom of Socket-ASocketBore Dia.Of FittingSocket Wall Thickness2Body Wall ThicknessDepth
PipeBoreDCGof
Size90°Elbows45°ElbowsDia.
Class DesignationClass DesignationSocket

Class DesignationClass DesignationBClass Designation300060009000300060009000Min.

300060009000300060009000
300060009000Ave.Min.Ave.Min.Ave.Min.Min.Min.Min.J
61/8"1111---88---10.86.94---3.183.183.963.43------2.413.15---9.5
81/4"1113.5---88---14.29.36.4---3.783.34.64.01------3.023.68---9.5
103/8"13.515.5---811---17.612.69.2---4.013.55.034.37------3.24.01---9.5
151/2"15.51925.51112.515.521.815.811.86.44.674.095.975.189.358.183.734.787.479.5
203/4"1922.528.513141927.22115.611.14.94.276.966.049.788.563.915.567.8212.5
251"22.527321417.520.533.926.720.715.25.694.987.926.9311.389.964.556.359.0912.5
321-1/4"27323517.520.522.542.735.129.522.86.075.287.926.9312.1410.624.856.359.712.5
401-1/2"32383820.525.525.548.840.934286.355.548.927.812.711.125.087.1410.1512.5
502"38415425.528.528.561.252.542.938.26.936.0410.929.513.8412.125.548.7411.0716
652-1/2"41------28.5------73.962.7------8.767.67------------7.01------16
803"57------32------89.878------9.528.3------------7.62------16
1004"66.5------41------115.2102.3------10.699.35------------8.56------16

(1) Dimensions in Millimeters.

(2) Average of socket wall thickness around periphery shall be no less than listed values. The minimum values are permitted in localized areas.

(3) Upper and lower values for each size are the respective maximum and minimum dimensions.
